CIN::APSE ?
High-Speed Interconnect Technology
1
TYPICAL CONFIGURATION
1. Button-Only
This is the basic CIN::APSE contact configuration. It is ideally suited for
z-axis applications requiring minimum height, high density, and signal
integrity. This configuration is used in LGA and IC sockets, PCB to PCB,
and flex print circuit to PCB applications.
2. Plunger-Button
The addition of a gold-plated brass plunger increases the durability of the
CIN::APSE contact system while also achieving additional height. This
configuration suits itself especially well for PCB to PCB interconnect and
those that require excessive handling.
Other custom configurations are
available. Contact Cinch for details.
CIN::APSE Applications
Due to its breakthrough nature, it is impossible to illustrate all of the applications CIN::APSE
technology can address. The following applications illustrate only a portion of the types of
interconnect problems that CIN::APSE can solve.
Call Toll Free: 1 (800) 323-9612
1-3
